Aluminum-coated step index multimode silica fibers CCR 1.1 (High OH)

Aluminum-coated step index multimode silica fibers CCR 1.1 (High OH)
Aluminum-coated step index multimode optical fibers (Core/Clad Ratio 1.1) have all the benefits of silica-silica fibers. Additional significant improvements include increased mechanical strength and greater fatigue resistance compared to non-hermetic and polymer-clad fibers (PCS). Their transmittance covers a spectral range of 250 to 1200 nm, and also remains stable in corrosive chemicals that normally react to silica glass. The temperature range is from -196C to +400C.

FEUTURES:
  • Greatly enhanced resistance to high power laser radiation.
  • Higher core-to-clad ratio and enlarged NA optimized for coupling to high-energy lasers.
  • Better fiber cooling due to the heat-conducting metal coating.
  • Excellent mechanical strength and flexibility compared to polymer coated fibers.
  • The metal coating can be soldered and will not outgas.



General Properties
Core diameter, µm Clad diameter, µm Coating diameter, µm Cladding offset, % Coating offset, %
200 ± 4 220 ± 5 300 ± 15 < 2 < 5



General Properties
Core diameter, µm Clad diameter, µm Coating diameter, µm Cladding offset, % Coating offset, %
200 ± 4 220 ± 5 300 ± 15 < 2 < 5



General Properties
Core diameter,µm Clad diameter,µm Coating diameter,µm Cladding offset,% Coating offset,%
200 ± 4 220 ± 5 300 ± 15 < 2 < 5



Optical Properties
Core material Clad material Index profile Wavelength range, nm Attenuation at 800/1300 nm
Pure syntetic silica Doped silica Step 250 - 1200 the loss spectrum in the long wavelength region ( > 1um) is higher than that of the material



Optical Properties
Core material Clad material Index profile Wavelength range, nm Attenuation at 800/1300 nm
Pure syntetic silica Doped silica Step 250 - 1200 the loss spectrum in the long wavelength region ( > 1um) is higher than that of the material



Optical Properties
Core material Clad material Index profile Wavelength range, nm Attenuation at 800/1300 nm
Pure syntetic silica Doped silica Step 250 - 1200 the loss spectrum in the long wavelength region ( > 1um) is higher than that of the material



Operating conditions
Proof test, kpsi Numerical Aperture (NA) Min operating temperature, C Max operating temperature, C Short-term/Long-term bending radius
100 0.22 ± 0.02 -196 400 60 times/120 times the fiber diameters



Operating conditions
Proof test, kpsi Numerical Aperture (NA) Min operating temperature, C Max operating temperature, C Short-term/Long-term bending radius
100 0.22 ± 0.02 -196 400 60 times/120 times the fiber diameters



Operating conditions
Proof test, kpsi Numerical Aperture (NA) Min operating temperature,C Max operating temperature,C Short-term/Long-term bending radius
100 0.22 ± 0.02 -196 400 60 times/120 times the fiber diameters
