High non-linear fiber
HNLF
High non-linear fiber HNLF series is designed to maximize fiber nonlinearity and minimize optical loss, which makes such fibers optimal for constructing highly efficient Raman lasers and amplifiers, dispersion compensators and various non-linear devices.
High non-linear fiber | HNLF |
| Core diameter, µm | 3.0 ± 1 |
| Clad diameter, µm | 125 ± 1 |
| Core NA | ~ 0.3 |
| MFD @ 1550nm, µm | ~ 4 |
| Dispersion @1550nm, ps/nm/km | < - 50 |
| Cutoff wavelength, µm | 1 ± 0.3 |
| Optical loss (1550 nm), dB/km | < 5 |
| Nonconcentricity, µm | < 0.5 |
| Zero dispersion wavelength, nm | > 2300 |
Other parameters including core NA > 0.6 (pure GeO2 core) and PM version are available on the request
