High non-linear fiber with shifted dispersion
HNLF DS
High non-linear fibers with shifted dispersion HNLF DS series is designed for applications requiring a shift of the zero dispersion wavelength to the 1550 nm spectral region: supercontinuum generation, parametric conversion and etc.
High non-linear fiber with shifted dispersion | HNLF DS |
| Core diameter, µm | 4.5 ± 1 |
| Clad diameter, µm | 125 ± 1 |
| Core NA | ~ 0.3 |
| MFD @ 1550nm, µm | ~ 4 |
| Dispersion @1550nm, ps/nm/km | ± 4 |
| Cutoff wavelength, µm | 1.5 ± 0.5 |
| Optical loss (1550 nm), dB/km | < 5 |
| Nonconcentricity, µm | < 0.5 |
| Zero dispersion wavelength, nm | 1480-1565 |
Other parameters including core and PM version are available on the request
