Thulium-Ytterbium codoped fiber
TYDF-DC-10/125
Thulium-Ytterbium codoped fiber TYDF-DC-10/125 series is specially designed for highly efficient pumping with MM pump sources at 915/975nm. Pumping with conventional sources near 790 nm is also possible, as well as core pumping with EDFL operating at 1550-1600nm.
Thulium-Ytterbium codoped fiber | TYDF-DC-10/125 |
| Core diameter, µm | 11.0 ± 1.5 |
| Clad diameter, µm | 125 ± 3 |
| Clad shape | square |
| Core NA | 0.22 ± 0.04 |
| Clad NA | 0.44 ± 0.02 |
| Cutoff wavelength, µm | 2.6 ± 0.1 |
| Clad absorption (915 nm), dB/m | > 3.5 |
| Clad absorption (976 nm), dB/m | > 5 |
Other parameters including PM version are available on the request
